JC-LGL 360 Degree PIR Occupancy Motion Sensor
JC-LGL 360 Degree PIR Occupancy Motion Sensor
JC-LGL 360 Degree PIR Occupancy Motion Sensor
JC-LGL 360 Degree PIR Occupancy Motion Sensor
JC-LGL 360 Degree PIR Occupancy Motion Sensor
JC-LGL 360 Degree PIR Occupancy Motion Sensor
JC-LGL 360 Degree PIR Occupancy Motion Sensor

PIR Motion Sensor 360 Degree

$39.99 USD $29.99 USD SAVE 25%
✓ Factory Direct & 5-Year Warranty & Quality Assured
✓ Bulk Savings — Lower Price Per Light on Larger Packs
✓ Spend $1000, Get $100 Off - Limited Time

pack: 2 pack

2 pack
4 pack
Compare

Guaranteed Safe Checkout

visapaypalmastermaestroamerican expressdiscoverapple paygoogle payjcbdiners clubafterpay
Size GuideDelivery & ReturnAsk a Question
Order in the next [totalHours] hours %M minutes to get it between and

30 Days Free Returns

The ANT-6-4T mounts in an outdoor lighting fixture and provides multi-level control based on motion and/or daylight contribution.It controls 0-10V DC LED drivers or dimming ballasts, and is rated for wet and cold locations. All control parameters are adjustable via a wireless configuration tool capable of storing

Specifications

• Powersupply: 12V-24V DC，>30mA
• Dim control output: 0-10v，max.25mA sinking current
• Remote range: 50ft.(15m)indoor.no backlight
• Detection radius: 20%/50%/75%/100%（1-8m）
• Mounting height: Max40ft.(12meters)
• Time setting: 10s/1min/5min/10min/15min/20min/30min/60min
• Light-control: 24H/10LUX/30LUX/50LUX
• Temperature: -40°F~+158°F（-40C~+70°C)
• IP rating: IP65

Applications

This PIR Sensor is suitable for JC-LGL High Bay Lights

Document

📝PIR Motion Sensor 360 Degree

📝JC-LGL PIR Sensor ANT-6-4T Manual

User Guide

📝Dusk to Dawn Photocell vs. PIR Sensor: Which is Better?

📝What is The Best Height for a LED High Bay Light?

📝Installation Guide for Linear High Bay Lights

❗AWARNING
  • NOTE: Warm-up time is 40 seconds. After the sensor connects input power first time, the light will keep on 40 seconds, then go to dimming to work normally.
  • NOTE: Factory Default Setting: 100% sensitivity,Hold on time: 5 min,Daylight sensor is ☀, Dimming level: 30%, Dimming time: 60 minutes.
  • NOTE: Any setting changed by remote control, the LED light that sensor connect will on/off as confirm.

❗【NOTICE】This PIR Sensor is suitable for JC-LGL High Bay Lights






LED Linear High Bay Light with PIR Sensor LED Linear High Bay Light with PIR Sensor LED Linear High Bay Light with PIR Sensor LED Linear High Bay Light with PIR Sensor
