JC-LGL LED Linear High Bay Lights 130W-400W Power And Color Temperatures Adjustable
The JC-LGL LED linear high bay light adopts high efficiency LED chip, the luminous efficacy is up to 150LM/W. The device offers adjustable wattage and correlated color temperature (CCT) functionality. Specifically, wattage can be configured to 100%, 80%, 60%, or 40%, while CCT is selectable between 4000K and 5000K. This light are made of rugged cold-rolled steel plate corrosion-resistant housing, and an excellent thermal management system effectively extends the service life of the fixture. Ultra-Compact, strudy design saves freight and space on lifts and racks during instllation, making it ideal for warehousing, large indoor spaces, retail and commercial applications.
Specifications
Applications
Document
📝4000K&5000K Linear High Bay Lights With PIR, Power And Color Temperatures Adjustable Manual
📝 JC-LGL Linear High Bay Light Wiring Installation Manual
User Guide
📝📝JC-LGL High Bay LED Light Installation Manual 📝How to calculate how many lights you need? 📝What is The Best Height for a LED High Bay Light? 📝UFO LED High Bay In-Depth Review 📝Guide to choosing the best led ufo high bay light! 📝How many lumens do you need for barn lighting? 📝How Many Lumens Do LED High Bay Lights Need for Bright Commercial Spaces?
Product Case Video
Our Community's Favorite Moments Love For JC-LGL
💡Why choose our LED Linear High Bay Lights
4 Wattages & 2 Color Temperatures
Configure wattage at 100%, 80%, 60% or 40% and select 4000K or 5000K to match the space and task.
Ultra-Durable High Bay Light with 150LM/W Efficiency
Built with a corrosion-resistant cold-rolled steel housing and advanced air-vent thermal management for exceptional durability. Delivers 150LM/W bright, energy-saving illumination via high-transmittance anti-glare PC lens, featuring an L70 estimated lifespan of >70,000 hours @ 77°F for long-term, low-maintenance performance.
UL, FCC & RoHS — 5-Year Warranty
UL verifies US electrical safety, FCC confirms electromagnetic compatibility, and RoHS verifies restricted hazardous substances — backed by a 5-year warranty.
Easy Installation
Follow the installation guide and use the included hanging chain for quick setup.
Typical Height of Installation
Use the installation-height guidance provided for this high-bay series.
Wide Application
Suitable for warehouses, logistics centers, auto garages, manufacturing plants, gyms, supermarkets, barns and high-ceiling exhibition halls.
LED Linear High Bay Shop Lights
| Comparison Item | Basic Series | Basic Series+Motion senor | Wattage and CCT adjustable Series | Wattage and CCT adjustable Series + Motion Series |
|---|---|---|---|---|
| Product Images |  |  | | |
| Input Voltage | AC 100-277V | AC 100-277V | AC 100-277V | AC 100-277V |
| Max Delivered Lumens | 19,500lm(130W)/ 31,500lm(210W)/ 45,000lm(300W)/ 60,000lm(400W) | 19,500lm(130W)/ 31,500lm(210W)/ 45,000lm(300W)/ 60,000lm(400W) | 19,500lm(130W)/ 31,500lm(210W)/ 45,000lm(300W)/ 60,000lm(400W) | 19,500lm(130W)/ 31,500lm(210W)/ 45,000lm(300W)/ 60,000lm(400W) |
| wattage adjustable | × | × | adjustable 100%-80%-60%-40% | adjustable 100%-80%-60%-40% |
| CCT | 5000K | 5000K | adjustable 4000K-5000K | adjustable 4000K-5000K |
| CRI | ≥ 70 | ≥ 70 | ≥ 70 | ≥ 70 |
| Dimmable | 0-10V | 0-10V | 0-10V | 0-10V |
| Protection Grade | IP65 | IP65 | IP65 | IP65 |
| Certificates | FCC/RoHS/UL | FCC/RoHS/UL | FCC/RoHS/UL | FCC/RoHS/UL |
| Beam Angle | 90° | 90° | 90° | 90° |
| sensor | × | With PIR sensor | × | With PIR sensor |
Number of fixtures needed: 0
Layout: 0 x 0
Spacing: 0.0 x 0.0 ft
support@jclgl-led.com
Electricity Cost Calculator
Electricity Cost
Frequently asked questions
How many color temperature options can be switched on site?
What beam angle and CRI value does the lamp adopt?
What dust & water protection grade? Suitable for damp locations?
What typical indoor application scenes for this adjustable linear high bay?
How to adjust wattage and CCT during installation?
