JC-LGL LED Linear High Bay Shop Lights 130W-400W, Motion Activated Series
The JC-LGL LED linear high bay light adopts high efficiency LED chip, the luminous efficacy is up to 150LM/W. Using only 130W/210W/300W/400W power can emit 19,500lm / 31,500lm / 45,000 / 60,000 lumens of high quality lights , with a daylight color temperature of 5000K. This light are made of rugged cold-rolled steel plate corrosion-resistant housing, and an excellent thermal management system effectively extends the service life of the fixture. Ultra-Compact, strudy design saves freight and space on lifts and racks during instllation, making it ideal for warehousing, large indoor spaces, retail and commercial applications.
Specifications
Applications
Document
📝5000K Linear High Bay Lights With PIR Manual
📝 JC-LGL Linear High Bay Light Wiring Installation Manual
📝 JC-LGL Linear High Bay Light Remote Manual
📝 JC-LGL PIR Sensor ANT-6-4T Manual
User Guide
📝📝JC-LGL High Bay LED Light Installation Manual 📝How to calculate how many lights you need? 📝What is The Best Height for a LED High Bay Light? 📝UFO LED High Bay In-Depth Review 📝Guide to choosing the best led ufo high bay light! 📝How many lumens do you need for barn lighting? 📝How Many Lumens Do LED High Bay Lights Need for Bright Commercial Spaces?
Product Case Video
Our Community's Favorite Moments Love For JC-LGL
💡Why choose our LED Linear High Bay Lights
Motion Sensing That Reduces Waste
The PIR sensor provides 360° wide detection coverage; the light runs at full brightness when movement is detected and automatically dims to 30% output when no activity is detected.
Ultra-Durable High Bay Light with 150LM/W Efficiency
Built with a corrosion-resistant cold-rolled steel housing and advanced air-vent thermal management for exceptional durability. Delivers 150LM/W bright, energy-saving illumination via high-transmittance anti-glare PC lens, featuring an L70 estimated lifespan of >70,000 hours @ 77°F for long-term, low-maintenance performance.
UL, FCC & RoHS — 5-Year Warranty
UL verifies US electrical safety, FCC confirms electromagnetic compatibility, and RoHS verifies restricted hazardous substances — backed by a 5-year warranty.
Easy Installation
Follow the installation guide and use the included hanging chain for quick setup.
Typical Height of Installation
Use the installation-height guidance provided for this high-bay series.
Wide Application
Suitable for warehouses, logistics centers, auto garages, manufacturing plants, gyms, supermarkets, barns and high-ceiling exhibition halls.
LED Linear High Bay Shop Lights
| Comparison Item | Basic Series | Basic Series+Motion senor | Wattage and CCT adjustable Series | Wattage and CCT adjustable Series + Motion Series |
|---|---|---|---|---|
| Product Images |  View Product → |  View Product → | View Product → | View Product → |
| Input Voltage | AC 120-277V | AC 120-277V | AC 120-277V | AC 120-277V |
| Max Delivered Lumens | 19,500lm(130W)/ 31,500lm(210W)/ 45,000lm(300W)/ 60,000lm(400W) | 19,500lm(130W)/ 31,500lm(210W)/ 45,000lm(300W)/ 60,000lm(400W) | 19,500lm(130W)/ 31,500lm(210W)/ 45,000lm(300W)/ 60,000lm(400W) | 19,500lm(130W)/ 31,500lm(210W)/ 45,000lm(300W)/ 60,000lm(400W) |
| wattage adjustable | × | × | adjustable 100%-80%-60%-40% | adjustable 100%-80%-60%-40% |
| CCT | 5000K | 5000K | adjustable 4000K-5000K | adjustable 4000K-5000K |
| CRI | ≥ 70 | ≥ 70 | ≥ 70 | ≥ 70 |
| Dimmable | 0-10V | 0-10V | 0-10V | 0-10V |
| Protection Grade | IP65 | IP65 | IP65 | IP65 |
| Certificates | FCC/RoHS/UL | FCC/RoHS/UL | FCC/RoHS/UL | FCC/RoHS/UL |
| Beam Angle | 90° | 90° | 90° | 90° |
| sensor | × | With PIR sensor | × | With PIR sensor |
Number of fixtures needed: 0
Layout: 0 x 0
Spacing: 0.0 x 0.0 ft
support@jclgl-led.com
JC-LGL LIGHTING STUDIO
3D Lighting Design Simulator
Plan indoor and outdoor LED lighting with JC-LGL fixtures across 24 scenes. Set dimensions in feet, drag up to 100 fixtures into place, and compare estimated illuminance and power.
Looking for 3D lighting simulation design? Please visit JC-LGL 3D Lighting Studio to view recommended lamps for different scenarios, lamp placement, 3D lighting effects, and plan for saving the scheme.
