La luminaria lineal de bahía alta LED JC-LGL adopta un chip LED de alta eficiencia, con una eficacia luminosa de hasta 150 LM/W. El dispositivo ofrece funcionalidad de potencia y temperatura de color correlacionada (CCT) ajustables. Específicamente, la potencia se puede configurar al 100%, 80%, 60% o 40%, mientras que la CCT es seleccionable entre 4000K y 5000K.
Esta luminaria está fabricada con una carcasa de acero laminado en frío resistente a la corrosión y un excelente sistema de gestión térmica que prolonga eficazmente la vida útil del equipo. Su diseño ultracompacto y robusto ahorra espacio y costos de envío en montacargas y estanterías durante la instalación, lo que la hace ideal para almacenamiento, grandes espacios interiores, aplicaciones minoristas y comerciales.
📝Manual de luces lineales de bahía alta de 5000K con PIR
📝 Manual de instalación del cableado de la luz lineal de bahía alta JC-LGL
📝 Manual del control remoto de la luz lineal de bahía alta JC-LGL
📝📝Manual de instalación de la lámpara LED de bahía alta JC-LGL 📝¿Cómo calcular cuántas luces necesitas? 📝¿Cuál es la mejor altura para una lámpara LED de bahía alta? 📝Revisión en profundidad de la lámpara LED de bahía alta UFO 📝¡Guía para elegir la mejor lámpara LED UFO de bahía alta! 📝¿Cuántos lúmenes necesitas para la iluminación de graneros? 📝¿Cuántos lúmenes necesitan las lámparas LED de bahía alta para espacios comerciales luminosos?
Configure wattage at 100%, 80%, 60% or 40% and select 4000K or 5000K to match the space and task.
The PIR sensor provides 360° wide detection coverage; the light runs at full brightness when movement is detected and automatically dims to 30% output when no activity is detected.
UL verifies US electrical safety, FCC confirms electromagnetic compatibility, and RoHS verifies restricted hazardous substances — backed by a 5-year warranty.
Built with a corrosion-resistant cold-rolled steel housing and advanced air-vent thermal management for exceptional durability. Delivers 150LM/W bright, energy-saving illumination via high-transmittance anti-glare PC lens, featuring an L70 estimated lifespan of >70,000 hours @ 77°F for long-term, low-maintenance performance.
Follow the installation guide and use the included hanging chain for quick setup.
Use the installation-height guidance provided for this high-bay series.
Suitable for warehouses, logistics centers, auto garages, manufacturing plants, gyms, supermarkets, barns and high-ceiling exhibition halls.
| Comparison Item | Basic Series | Basic Series+Motion senor | Wattage and CCT adjustable Series | Wattage and CCT adjustable Series + Motion Series |
|---|---|---|---|---|
| Product Images |  |  | | |
| Input Voltage | AC 120-277V | AC 120-277V | AC 120-277V | AC 120-277V |
| Max Delivered Lumens | 19,500lm(130W)/ 31,500lm(210W)/ 45,000lm(300W)/ 60,000lm(400W) | 19,500lm(130W)/ 31,500lm(210W)/ 45,000lm(300W)/ 60,000lm(400W) | 19,500lm(130W)/ 31,500lm(210W)/ 45,000lm(300W)/ 60,000lm(400W) | 19,500lm(130W)/ 31,500lm(210W)/ 45,000lm(300W)/ 60,000lm(400W) |
| wattage adjustable | × | × | adjustable 100%-80%-60%-40% | adjustable 100%-80%-60%-40% |
| CCT | 5000K | 5000K | adjustable 4000K-5000K | adjustable 4000K-5000K |
| CRI | ≥ 70 | ≥ 70 | ≥ 70 | ≥ 70 |
| Dimmable | 0-10V | 0-10V | 0-10V | 0-10V |
| Protection Grade | IP65 | IP65 | IP65 | IP65 |
| Certificates | FCC/RoHS/UL | FCC/RoHS/UL | FCC/RoHS/UL | FCC/RoHS/UL |
| Beam Angle | 90° | 90° | 90° | 90° |
| sensor | × | With PIR sensor | × | With PIR sensor |
Number of fixtures needed: 0
Layout: 0 x 0
Spacing: 0.0 x 0.0 ft
Easy to mount with the supplied cables. Light output is more than expected for the price. I have mine about 12 foot from the ground and still spreads the light over a wide area. I used 4 in a 40x45 shop.
Great for the workshop! Does not have a plug pre-wired, you will need to hardwire this light or install a plug for your application.
I picked up a 4-pack of these JC-LGL 210W LED Linear High Bay Lights to light my fairly large 1600 sq ft shop/garage, and wow... four of them make the place feel like the Las Vegas Strip at night.
The 31500 lumens per fixture (that's over 120,000 total lumens with four!) is no joke—everything is lit up crystal clear, no shadows, no dark corners. Colors pop, details stand out, and I can finally see every little thing while working on projects. It was so good that I immediately bought another 4-pack to crank it up to full "surface of the sun" brightness. With eight, this shop is brighter than most commercial warehouses I've been in—perfect for detailed work, safety, and just making the space feel huge and inviting.
Easy to install—the adjustable hangers are a game-changer. They let you fine-tune the height and angle perfectly without any hassle, whether you're hanging from rafters, beams, or a high ceiling. Came with chains/hooks (or you can use your own), and wiring was straightforward for 120-277V compatibility. I had all four up and running in under an hour—no special tools beyond a ladder and basic wiring know-how. Super solid build too.
Low power usage for the insane amount of light these produce is impressive. At 210W each, they're efficient (high lumens per watt), so even with eight running, my electric bill isn't going to explode compared to old fluorescents or halogens that put out way less. Energy-saving win for daily use in a big shop.
Haven't wired up the dimmer functionality yet (0-10V dimmable, so it should integrate nicely with a controller or switch), but from the specs, it looks simple enough—plan to add that soon for more control during different tasks or to dial it down for evenings.
These are UL-listed, durable for industrial/shop environments, and at this price for a 4-pack of high-output linear high bays, it's unbeatable value. If you need serious illumination for a garage, workshop, warehouse, or basement, these will blow you away. Highly recommend—grab extras like I did!
I track my shop's usage monthly and these cut it by a third. The wattage adjustment and motion sensor together make a real dent.
We lit up our horse barn with these. The 4000K setting is a nice neutral light and they handle the dust and humidity fine. Solid fixtures for farm use.
Our shop has 18ft ceilings and the light reaches the floor easily. The 90 degree beam does exactly what it should.
These lights transformed my farm shop. The old metal halides are gone and it's brighter and cooler in here. The high-efficiency chips run much cooler too.
So far very bright but we will see how long they last. I''m installing these to replace the last leds that only lasted 1 years
Very bright. We have them mounted about 12ft high. We’re going to be changing many linear high bay led lights in the near future
This light is very well constructed. It feels solid and looks good (for a shop light). Most importantly, is also UL certified (see picture).It was a somewhat smaller than what I was expecting. The pictures would indicate that it is a 2x4 light. This is considerably smaller at 42L x 25W x 4.4H Centimetres (16.54L x 9.84W x 1.762H Inches). After I received the item, I rechecked the listing and found the dimensions further down the page under the pull down Measurements. The pictures are misleading...Having said all of that, I found a use/purpose for this light. It is fairly easy to install. I have chosen to install this using a suitable sized extension cord (with one end cut off and connected to the light wiring) so that I can plug it into a power bar to make it easier to turn off and on (installed over small bench grinder table).This is a very bright light. Depending on your purpose, you may want to adjust the output to suit your needs by utilizing the selector switches on the top of the unit (see picture).Overall, a very nice light.
This light is seriously powerful - almost too powerful! I had to dial it down to half brightness because it was blinding at full strength (no pun intended). Thankfully, it comes with adjustable switches for both brightness and color temperature, which made it easy to customize for my garage setup.Before installing, I ran extended tests and noticed the LED controller brick can get quite hot - over 60°C. Lowering the power helped keep it in the 50-55°C range, which feels safer and more suitable for long-term use. The controller brick has a UR certification, which gives me peace of mind considering how much power this thing pushes.Overall, this fixture could easily be a one-light solution for any workshop or garage. My only wish is that it came with a remote control (since typical installation height for this is out of reach) and a more protective cover or casing (for better wiring safety). Still, for the brightness, adjustability, and build quality, it's a solid choice.
Completely caught off guard by this little lamp. I was expecting a 4' long shop light. The advertisement had no measurements so I included them in the title. If I hadn't received this for review, I would have been disappointed. However, I actually quite like the size.It's nice that it can be wired for dimming which can be a necessity with this bright highway lights when used in a normal home. Also,It has a mock dimming feature where you can select a lower voltage. But it's not mood lighting. 🤣🤣The instructions are pretty minimal and there are some interesting features with zero explanation. I am assuming the removable back is so you can stuff the grommets inside when you connect the electrical wires. I have no idea what's going on with the front removable cover.The only negative for me as a homeowner is that there is no included cover for the wiring box. All the wires are exposed as well and you grommets just hanging out. I like the brand and this is a perfect light for a shed, small garage, etc.TIP: Give yourself more than you think you need so you don't have to completely redo the wiring if you change your mind on the height. The excess, within reason, can be tucked in the ceiling.
Work great. Good quality led. kind of expensive but worth it in my opinion. I bought 8 for a 40x60 barn. Super bright would definitely recommend. They came with the air craft cable so the install was easy enough.
Not bulky, gives the light that's needed.
This light puts out a lot of bright light which would be perfect in a dark section of a garage or over a workbench.
The cables to hang it have easy adjustments which is very handy. A press of a button allows you to lower or raise the height without any tools. A couple of properly spaced hooks above allows you to do the physical installation in no time.
The light does put out some heat but not as much as some I've seen and it never got too hot that I wasn't able to touch the housing.
The light is only 16 inches long but it puts out more light than my 48 inch florescent fixture did. This is definitely a great upgrade in terms of light quality and energy efficiency.
I priced commercial high bays from supply houses and these were a fraction of the cost with the same specs. Excellent value for a small business.
Our 5000sqft warehouse has 20ft ceilings and these light every corner. No more dark zones where I used to trip over pallets. Massive improvement.
I run an auto repair shop and these lights are exactly what I needed. Even light across the bays, no dark corners under the lifts. Customers have commented on how clean the shop looks.
The light is beautifully even across the whole shop floor. No shadows, no dark spots. Exactly what a workspace needs.
The workshop is now my favorite room in the house. These lights are bright, clean, and make everything look better.
I use mine in my craft studio. The bright, color-accurate light is perfect for matching fabrics and paints. The adjustable brightness is a bonus.
Our home garage finally has proper lighting. Everything is visible, and the light is easy on the eyes.
Our workshop used to eat electricity with old metal halide fixtures. These linear high bays use a fraction of the power for better light. The payback was faster than I expected.
