JC-LGL 1x4 LED Flat Panel Light Surface Mount| 6500LM, 30W/40W/50W & 5CCT Selectable, TRIAC Dimmable
Pago Seguro Garantizado
Devoluciones gratuitas en 30 días
Upgrade fluorescent ceiling fixtures with a brighter and more flexible lighting solution. The JC-LGL 1x4 LED Flat Panel Light delivers up to 6,500 lumens while allowing installers to select 30W, 40W or 50W output according to the room’s lighting requirements.Five selectable color temperatures—3000K, 3500K, 4000K, 5000K and 6500K—make it easy to create anything from warm, comfortable illumination to crisp daylight. Compatible TRIAC dimming provides smooth 10%–100% brightness control for additional flexibility.The durable aluminum housing promotes efficient heat dissipation, while the advanced back-lit panel produces uniform, comfortable illumination without visible flicker or distracting noise. Its slim surface-mounted profile creates a clean, modern ceiling appearance in residential, institutional and commercial interiors.
Specifications
Applications
Document
User Guide
Product Case Video
💡Why choose our LED Flat Panel Light 1FT × 4FT Surface Mount
3 Selectable Wattages & 5 Color Temperatures
Choose between 30W, 40W or 50W and select from 3000K, 3500K, 4000K, 5000K or 6500K using the built-in switches before installation.
One Panel, Endless Applications
Ideal for offices, kitchens, classrooms, schools, churches, restaurants, basements, garages, hospitals, gyms and meeting rooms.
ETL, cETL, FCC, CE & RoHS Certified
Certified to ETL, cETL, FCC, CE and RoHS standards for electrical safety, electromagnetic compatibility and environmental compliance, backed by a 5-year warranty.
Cool, Bright & Up to 85% More Efficient
Efficient heat dissipation, uniform high-output illumination, 50,000-hour LED chips and a quiet advanced driver deliver dependable lighting while using up to 85% less energy. Supports 100–277V AC input.
Built Strong, Designed for Eye Comfort
An aluminum backplate, anti-static dust-resistant panel and sturdy metal frame provide lasting durability, while the branded quiet driver delivers flicker-free illumination, up to 120 lm/W and a 50,000-hour lifespan.
Smooth TRIAC Dimming, No Flicker or Buzz
Compatible with standard TRIAC dimmers for smooth brightness control, with instant-on, flicker-free and noise-free performance across a 100–277V AC input range. Dimmer is not included.
Fits Drop and Solid Ceilings
Designed for installation on both drop ceilings and solid ceilings, with a simple four-step mounting process for secure commercial and residential installation.
LED Panel Lights
| Comparison Item | 1x4 FT Surface Mount LED Panel Light | 1x4 FT Panels Light | 2x2 FT Panels Light | 2x4 FT Panels Light |
|---|---|---|---|---|
| Product Images |  View Product → |  View Product → |  View Product → |  View Product → |
| Dimension | 1198 × 298 × 36mm | 303x1213x35mm | 603x603x35mm | 603x1213x35mm |
| Input Voltage | AC100-277V | AC100-277V | AC100-277V | AC100-277V |
| Max Delivered Lumens | 6,500lm (50W) | 5,200lm(40W) | 5,200lm(40W) | 9,360lm(72W) |
| wattage adjustable | Adjustable: 50W / 40W / 30W | adjustable 40W-35W-30W-25W-20W | adjustable 40W-35W-30W-25W-20W | adjustable 72W-60W-50W-40W-30W |
| CCT | Adjustable: 3000K / 3500K / 4000K / 5000K / 6500K | adjustable 3000K-3500K-4000K-5000K-6500K | adjustable 3000K-3500K-4000K-5000K-6500K | adjustable 3000K-3500K-4000K-5000K-6500K |
| CRI | ≥ 80 | ≥ 80 | ≥ 80 | ≥ 80 |
| Dimmable | TRIAC, 10%-100% | 0-10V | 0-10V | 0-10V |
| Certificates | ETL/cETL/FCC/CE/RoHS | ETL/cETL/FCC/CE/RoHS | ETL/cETL/FCC/CE/RoHS | ETL/cETL/FCC/CE/RoHS |
| Beam Angle | 120° | 120° | 120° | 120° |
